Showing 1–12 of 58 results

  • ACRA 1440GWI Gear-Head Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> Capacity: 14″/20″ x 40″ Swing Over Bed:  14″ Swing Over Cross Slide:  8-1/4″ Swing In Gap:  20″ Length of Gap: 9-3/8″ Distance Between Centers: 40″ Spindle Bore:  1-1/2″ Spindle Nose:  D1-4 Spindle RPM:  40 – 1,800 (12 Speeds) Spindle Bearing Type: Taper Roller Bearing Longitudinal Feeds: 0.0011″~0.0271″/rev. Cross Feeds: 0.0003″~0.01″/rev Inch Treads(28): 4-56 TPI Metric Threads(37): 0.45mm~7.0mm Maximum Tool Size: 1″x1″ Compound Slide Travel: 3-1/2″ Cross Slide Travel: 6″ Carriage Travel: 37″ Tailstock Travel: 4-5/4″ Diameter of Tailstock: 1-7/10″ Tailstock Taper: MT#3 Main Motor:  4 HP Voltage: 220/440V AC / 3PH <strong>Standard Equipment:</strong> <ul> <li>260mm (10-1/4″) extra wide bed ways with harden and grounded</li> <li>Available with three phases or single phase motor</li> <li>One piece case iron floor stand</li> <li>Special larger 190mm (7″) D1-4 3 jaw scroll chuck</li> <li>ISO9000 Certified factory</li> <li>6″ 3 Jaw Chuck</li> <li>8″ 4 Jaw Chuck</li> <li>Steady/Follow Rest</li> <li>4 Way Tool Holder</li> <li>Coolant System</li> <li>Foot Brake</li> <li>Full Length Splash Guard</li> <li>Micro Bed Stop</li> <li>Chuck Guard</li> </ul>
    Call for Price
  • ACRA 1550C Precision Gap Bed Engine Lathe with Clutch

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong> 15″/24″ x 50″ Swing Over Bed: 15-1/4″ Swing Over Cross Slide: 9-3/8″ Swing In Gap: 24″ Distance Between Centers: 50″ Bed Width: 11″ <strong>Headstock:</strong> Spindle Nose: D1-6 Spindle Bore: 2-3/16″ Taper of Spindle: MT NO.5 Spindle Speeds – Steps: 16 step Spindle Speeds – Range: 25 ~ 2,000 RPM <strong>Carriage:</strong> Cross Slide Travel: 9-1/4″ Compound Slide Travel: 4-3/4″ <strong>Threads & Feeds:</strong> Inch Threads: 2~72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.002 ~ 0.067″/rev Cross Feeds: 0.001 ~ 0.0375″/rev <strong>Tailstock:</strong> Quill Diameter: 2-5/16″ Quill Travel: 5″ Quill Taper: MT NO.4 <strong>Power:</strong> Spindle Drive Motor: 7-1/2 HP Voltage: 230V/460V AC / 3 PH <strong>Standard Equipment:</strong> <ul> <li>8″ 3-Jaw Chuck</li> <li>10″ 4-Jaw Chuck</li> <li>Full Length Splash Guard</li> <li>Steady Rest/Follow Rest</li> <li>Coolant System</li> <li>Foot Brake</li> <li>Work Lamp</li> <li>Gap Bed</li> <li>4 position square tool post</li> <li>Tool box with tools</li> </ul>
    Call for Price
  • ACRA 1743ACH Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong> 17″/24″ x 43″ Swing Over Bed: 17″ Swing Over Cross Slide: 10-1/2″ Swing In Gap: 24″ Distance Between Centers: 43″ Bed Width: 12″ <strong>Headstock:</strong> Spindle Nose: D1-6 Spindle Bore: 2-1/4″ Taper of Spindle: MT NO.5 Spindle Speeds – Steps: 12 step Spindle Speeds – Range: 35 ~ 2,000 RPM <strong>Carriage:</strong> Cross Slide Travel: 6-1/2″ Compound Slide Travel: 4″ <strong>Threads & Feeds:</strong> Inch Threads: 2~72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.0012 ~ 0.039″/rev Cross Feeds: 0.0004 ~ 0.0117″/rev <strong>Tailstock:</strong> Quill Diameter: 2-3/8″ Quill Travel: 6″ Quill Taper: MT NO.4 <strong>Power:</strong> Spindle Drive Motor: 7.5 HP Voltage: 230/460V AC / 3 PH <strong>Standard Equipment</strong> <ul> <li>10″ 3-Jaw Chuck</li> <li>12″ 4-Jaw Chuck</li> <li>Steady Rest</li> <li>Full Length Splash Guard</li> <li>Coolant System</li> <li>4 Way Tool Holder</li> <li>Foot Brake</li> <li>Halogen Work Lamp</li> </ul>
    Call for Price
  • ACRA 22120ACH Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong> 22″/31″ x 120″ Swing Over Bed: 22″ Swing Over Cross Slide: 13-3/8″ Swing In Gap: 31-3/8″ Distance Between Centers: 120″ Bed Width: 15-3/4″ Center Height: 11″ <strong>Headstock:</strong> Spindle Nose: D1-11 Spindle Bore: 4-1/16″ Taper of Spindle: MT NO.7 x MT NO.5 Spindle Speeds – Steps: 12 Spindle Speeds – Range: 13 ~ 1,200 RPM <strong>Carriage:</strong> Cross Slide Travel: 15-3/4″ Compound Slide Travel: 9-1/2″ <strong>Threads & Feeds:</strong> Inch Threads: 2 ~ 72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.0012 ~ 0.039 in/rev Cross Feeds: 0.0004 ~ 0.0117 in/rev <strong>Tailstock:</strong> Quill Diameter: 2.935″ Quill Travel: 7″ Quill Taper: MT NO.5 <strong>Power:</strong> Spindle Drive Motor: 15 HP/4P Voltage: 230/460V AC/3 PH <strong>Standard Equipment:</strong> <ul> <li>MAIN MOTOR 15 HP</li> <li>CENTER SLEEVE MT No. 5</li> <li>DEAD CENTER MT NO. 5 X 2 PCs</li> <li>LEVELING SCREW AND BLOCK</li> <li>SERVICE KITS AND TOOL BOX</li> <li>STEADY REST- 1-5/8″~10″</li> <li>DRIVE PLATE- 12″ FOR D1-11 ONLY</li> <li>COOLANT SYSTEM</li> <li>MULTI – POSITION LENGTH STOP</li> <li>3 JAW SCROLL CHUCK- 15″</li> <li>FULL LENGTH SPLASH GUARD</li> <li>HALOGEN LIGHT</li> <li>4 WAY TOOL HOLDER</li> </ul>
    Call for Price
  • ACRA 2290ACH Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong> 22″/31″ x 90″ Swing Over Bed: 22″ Swing Over Cross Slide: 13-3/8″ Swing In Gap: 31-3/8″ Distance Between Centers: 90″ Bed Width: 15-3/4″ Center Height: 11″ <strong>Headstock:</strong> Spindle Nose: D1-11 Spindle Bore: 4-1/16″ Taper of Spindle: MT NO.7 x MT NO.5 Spindle Speeds – Steps: 12 Spindle Speeds – Range: 13 ~ 1,200 RPM <strong>Carriage:</strong> Cross Slide Travel: 15-3/4″ Compound Slide Travel: 9-1/2″ <strong>Threads & Feeds:</strong> Inch Threads: 2 ~ 72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.0012~0.039 in/rev Cross Feeds: 0.0004 ~ 0.0117 in/rev <strong>Tailstock:</strong> Quill Diameter: 2.935″ Quill Travel: 7″ Quill Taper: MT NO.5 <strong>Power:</strong> Spindle Drive Motor: 15 H.P./4P Voltage: 230/460V AC/3 PH <strong>Standard Equipment:</strong> <ul> <li>MAIN MOTOR 15 HP</li> <li>CENTER SLEEVE MT No. 5</li> <li>DEAD CENTER MT NO. 5 X 2 PCs</li> <li>LEVELING SCREW AND BLOCK</li> <li>SERVICE KITS AND TOOL BOX</li> <li>STEADY REST- 1-5/8″~10″</li> <li>DRIVE PLATE- 12″ FOR D1-11 ONLY</li> <li>COOLANT SYSTEM</li> <li>MULTI – POSITION LENGTH STOP</li> <li>3 JAW SCROLL CHUCK- 15″</li> <li>FULL LENGTH SPLASH GUARD</li> <li>HALOGEN LIGHT</li> <li>4 WAY TOOL HOLDER</li> </ul>
    Call for Price
  • ACRA 26120ACH Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong>  26″/35″ x 120″ Swing Over Bed: 26″ Swing Over Cross Slide: 17-1/2″ Swing In Gap: 35-1/8″ Distance Between Centers: 120″ Bed Width: 15-3/4″ <strong>Headstock:</strong> Spindle Nose: D1-11 Spindle Bore: 4-1/16″ Taper of Spindle: MT NO.7 x MT NO.5 Spindle Speeds – Steps: 12 Spindle Speeds – Range: 13 ~ 1,200 RPM <strong>Carriage:</strong> Cross Slide Travel: 15-3/4″ Compound Slide Travel: 9-1/2″> <strong>Threads & Feeds:</strong> Inch Threads: 2 ~ 72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.0012 ~ 0.039 in/rev Cross Feeds: 0.0004 ~ 0.0117 in/rev <strong>Tailstock:</strong> Quill Diameter: 2.935″ Quill Travel: 7″ Quill Taper: MT NO.5 <strong>Power:</strong> Spindle Drive Motor: 15 H.P./4P Voltage: 230/460V AC/3 PH <strong>Standard Equipment:</strong> <ul> <li>MAIN MOTOR 15 HP</li> <li>CENTER SLEEVE MT No. 5</li> <li>DEAD CENTER MT NO. 5 X 2 PCs</li> <li>LEVELING SCREW AND BLOCK</li> <li>SERVICE KITS AND TOOL BOX</li> <li>STEADY REST- 1-5/8″~10″</li> <li>DRIVE PLATE- 12″ FOR D1-11 ONLY</li> <li>COOLANT SYSTEM</li> <li>MULTI – POSITION LENGTH STOP</li> <li>3 JAW SCROLL CHUCK- 15″</li> <li>FULL LENGTH SPLASH GUARD</li> <li>HALOGEN LIGHT</li> <li>4 WAY TOOL HOLDER</li> </ul>
    Call for Price
  • ACRA 2690ACH Precision Gap Bed Engine Lathe

    Price:

    • Call for Price
    <strong>Specifications:</strong> <strong>Capacity:</strong>  26″/35″ x 90″ Swing Over Bed: 26″ Swing Over Cross Slide: 17-1/2″ Swing In Gap: 35-1/8″ Distance Between Centers: 90″ Bed Width: 15-3/4″ <strong>Headstock:</strong> Spindle Nose: D1-11 Spindle Bore: 4-1/16″ Taper of Spindle: MT NO.7 x MT NO.5 Spindle Speeds – Steps: 12 Spindle Speeds – Range: 13 ~ 1,200 RPM <strong>Carriage:</strong> Cross Slide Travel: 15-3/4″ Compound Slide Travel: 9-1/2″ <strong>Threads & Feeds:</strong> Inch Threads: 2 ~ 72 TPI Metric Threads: 0.2 ~ 14 mm Longitudinal Feeds: 0.0012 ~ 0.039 in/rev Cross Feeds: 0.0004 ~ 0.0117 in/rev <strong>Tailstock:</strong> Quill Diameter: 2.935″ Quill Travel: 7″ Quill Taper: MT NO.5 <strong>Power:</strong> Spindle Drive Motor: 15 H.P. Voltage: 230/460V AC/3 PH <strong>Standard Equipment:</strong> <ul> <li>MAIN MOTOR 15 HP</li> <li>CENTER SLEEVE MT No. 5</li> <li>DEAD CENTER MT NO. 5 X 2 PCs</li> <li>LEVELING SCREW AND BLOCK</li> <li>SERVICE KITS AND TOOL BOX</li> <li>STEADY REST- 1-5/8″~10″</li> <li>DRIVE PLATE- 12″ FOR D1-11 ONLY</li> <li>COOLANT SYSTEM</li> <li>MULTI – POSITION LENGTH STOP</li> <li>3 JAW SCROLL CHUCK- 15″</li> <li>FULL LENGTH SPLASH GUARD</li> <li>HALOGEN LIGHT</li> <li>4 WAY TOOL HOLDER</li> </ul>
    Call for Price
  • ACRA BS-250V Variable Speed Horizontal Bandsaw

    Price:

    • $5,850.00
    <strong>Specifications:</strong> Capacity (Round) 90°: 10″ Capacity (Round) 45°: 8-1/2″ Capacity (Rect.) 90°: 9″ x 16″ Capacity (Rect.) 45°: 10″ x 9-1/2″ Throat Depth: 10-1/2″ Swivel Base: 0 Degrees Bed Height: 23-1/2″ Blade Speeds: 82~259 FPM Blade Size: 1.06″ x 0.35″ x 130″ Main Motor: 2 HP Voltage: 220/440V AC/3 PH <strong>Standard Equipment:</strong> • Coolant System • Adjustable Hydraulic Down Feed • Blade Brush • Blade Guide • Fully Mitering • Automatic Shutoff • Bi-Metal Blade
    Add to cart
  • Acra FRD1300 Radial Arm Drilling Machine with Hydraulic Clamping

    Price:

    • Call for Price
    <strong>Specifications:</strong> Drilling Capacity Steel: 2-1/8″ Drilling Capacity Cast Iron: 2-1/2” Tapping Capacity Steel: 1-9/16” Tapping Capacity Cast Iron: 2” Boring Capacity Steel: 3.9” Boring Capacity Cast Iron: 6.8” Spindle Stroke: 9-7/8” Spindle Taper: MT#5 Spindle Speeds (12): 44-1,500 RPM Spindle Feeds: 0.002-0.012 IPR Column Diameter: 11-7/8” Spindle to Column Center: 21-3/4” ~ 55-1/2” Base to Spindle: 21-1/8” ~ 48-1/2” Horizontal Travel of Headstock: 36-1/8” Spindle Drive Motor: 5 HP Arm Elevation Motor: 2 HP Coolant Pump Motor: 1/8 HP Hydraulic Motor: 1 HP Voltage: 230/460V AC~3 Phase (2 Speed) <strong>Standard Equipment:</strong> • Coolant System • Box Table • Work Light • Emergency Stop • Toolbox • Manual & Parts List
    Call for Price
  • ACRA LCM-42 Vertical Variable Speed Milling Machine

    Price:

    • Call for Price
    <strong>Specifications:</strong> Table Size: 9″ X 42″ X Axis Travel: 30″ Y Axis Travel: 12″ Z Axis Travel: 5″ T-Slots: 3 x 0.625″ x 2.5″ Ram Travel: 12″ Knee Travel: 16″ Throat Distance: 6.75″ ~ 18.75″ Spindle to Table Top: 0 ~ 18.5″ Main Motor: 3 HP Spindle Nose: R-8 or #30 NST Spindle RPM: 60 – 4,500 RPM Quill Feeds: 0.0016″/0.0031″/0.0063″ Voltage: 230/460V AC~3 PH <strong>Standard Equipment</strong> Quill Heat Treated, Hardened & Chromed One Shot Lubrication Emergency Stop
    Call for Price
  • ACRA LCM50 Vertical Step Pulley Milling Machine

    Price:

    • Call for Price
    <strong>Specifications:</strong> Table Size:  9″ X 50″ X Axis Travel: 38″ >Y Axis Travel: 12″ Z Axis Travel:  5″ T-Slots: 3 x 0.625″ x 2.5″ Ram Travel:  12″ Knee Travel: 16″ Throat Distance: 6.75″ ~ 18.75″ Spindle to Table Top: 0 ~ 18.5″ Main Motor: 3 HP Spindle Nose: R-8 or #30 NST Spindle RPM: 80 – 5,520 RPM Quill Feeds: 0.0016″/0.0031″/0.0063″ Voltage: 230V AC ~ 3 PH <strong>Standard Equipment:</strong> Quill Heat Treated, Hardened & Chromed One Shot Lubrication Meehanite Casting Chrome Way
    Call for Price
  • ACRA LCTM-1 A/C Inverter Vertical Variable Speed Milling Machine

    Price:

    • Call for Price
    <strong>Specifications:</strong> Table Size:  10″ X 54″ T-Slots: 3 x 0.625″ x 2.5″ X Axis Travels: 35″ Y Axis Travels:  16.3″ Z Axis Travels (Quill): 5″ Main Motor: 3 HP Ram Travel: 18.5″ Knee Travel: 15.3″ Throat Distance: 9.6″ ~ 28.1″ Spindle to Table Top: 5.31″ ~ 20.7″ Spindle Nose: R-8 or #30 NST Spindle RPM:  60 – 4,500 RPM Quill Feeds: 0.0016″/0.0031″/0.0063″ Voltage: 230V AC ~ 1 PH/ 3 PH <strong>Standard Equipment:</strong> Quill Heat Treated, Hardened & Chromed One Shot Lubrication Emergency Stop Meehanite Casting Dual Cooling Fans A/C Inverter Drive
    Call for Price
