Summit Mill EVS Series



Summit Mill EVS Series

Key Features:



  • Inverter Duty, High Energy - High Efficiency Motors for lower utility costs, save up to 35%

  • Fewer moving parts in the head for less maintenance and down time

  • Cogged drive belt to prevent belt slippage and extend tool life

  • Centrally located controls for ease of operation

  • Immediate response speed control (0-full speed in 4 sec.)

  • Full range RPM selection. Tweak up or down to prevent chatter and prolong tool life

  • Electronic inverter controlled braking for reduced set-up time

  • "Turcite-B" inserted guideways for extended machine life

  • Complete electrics with low voltage controls for safer machine operation

  • Yaskawa compact AC inverter drive

  • Fan cooled electrical enclosure

  • Heavy "Maehanite" cast iron construction for excellent damping

  • Huge box ways on knee

  • Built in coolant system

  • Power feed on knee (EVS 550B)

  • One shot lubrication



  • Specifications: EVS-350B


  • Motor size (2 speeds) 3 HP

  • Spindle Speeds - number: Inf. variable

  • Spindle speeds - range (RPM): 0-4300

  • Spindle taper: R-8

  • Spindle Travel: 5"

  • Spindle feed range .0015/.003/.006

  • Head movement side to side: +/- 90

  • Head Movement front to back: +/- 45

  • Table size (WxLxH): 10"x50"x3-1/8"

  • Table feed (longitudinal): 36"

  • Table feed (cross) 16"

  • Maximum weight of work piece: 850 lbs.

  • Rotation of over arm: 360

  • Over arm adjustment: 22"

  • Spindle nose to table: 2-1/2" - 17-1/2"



  • Prices upon request.


    Specifcations and prices are subject to cahnge without notice.
